Creating an Android
Project PREVIOUS NEXT
An Android project contains all the
files that comprise the source code
for your Android app. The Android
SDK tools make it easy to start a new
Android project with a set of default
project directories and files.
This lesson shows how to create a
new project either using Eclipse
(with the ADT plugin) or using the
SDK tools from a command line.
Note: You should already have the
Android SDK installed, and if you're
using Eclipse, you should also have
the ADT plugin installed (version
21.0.0 or higher). If you don't have
these, follow the guide to Installing
the Android SDK before you start
this lesson.
Create a Project with Eclipse
1. Click New in the toolbar.
2. In the window that appears, open
the Android folder, select Android
Application Project, and click Next .
3. Fill in the form that appears:
Application Name is the app name
that appears to users. For this
project, use "My First App."
Project Name is the name of your
project directory and the name
visible in Eclipse.
Package Name is the package
namespace for your app (following
the same rules as packages in the
Java programming language). Your
package name must be unique
across all packages installed on the
Android system. For this reason, it's
generally best if you use a name
that begins with the reverse domain
name of your organization or
publisher entity. For this project,
you can use something like
"com.example.myfirstapp." However,
you cannot publish your app on
Google Play using the "com.example"
namespace.
Minimum Required SDK is the
lowest version of Android that your
app supports, indicated using the
API level . To support as many
devices as possible, you should set
this to the lowest version available
that allows your app to provide its
core feature set. If any feature of
your app is possible only on newer
versions of Android and it's not
critical to the app's core feature set,
you can enable the feature only
when running on the versions that
support it (as discussed in
Supporting Different Platform
Versions ). Leave this set to the
default value for this project.
Target SDK indicates the highest
version of Android (also using the
API level ) with which you have
tested with your application.
As new versions of Android become
available, you should test your app
on the new version and update this
value to match the latest API level
in order to take advantage of new
platform features.
Compile With is the platform
version against which you will
compile your app. By default, this is
set to the latest version of Android
available in your SDK. (It should be
Android 4.1 or greater; if you don't
have such a version available, you
must install one using the SDK
Manager ). You can still build your
app to support older versions, but
setting the build target to the latest
version allows you to enable new
features and optimize your app for a
great user experience on the latest
devices.
Theme specifies the Android UI style
to apply for your app. You can leave
this alone.
Click Next .
4. On the next screen to configure the
project, leave the default selections
and click Next.
5. The next screen can help you create
a launcher icon for your app.
You can customize an icon in several
ways and the tool generates an icon
for all screen densities. Before you
publish your app, you should be
sure your icon meets the
specifications defined in the
Iconography design guide.
Click Next .
6. Now you can select an activity
template from which to begin
building your app.
For this project, select BlankActivity
and click Next.
7. Leave all the details for the activity
in their default state and click
Finish .
Your Android project is now set up
with some default files and you’re
ready to begin building the app.
Continue to the next lesson.
Create a Project with
Command Line Tools
If you're not using the Eclipse IDE
with the ADT plugin, you can
instead create your project using the
SDK tools from a command line:
1. Change directories into the Android
SDK’s tools/ path.
2. Execute:
android list targets
This prints a list of the available
Android platforms that you’ve
downloaded for your SDK. Find the
platform against which you want to
compile your app. Make a note of
the target id. We recommend that
you select the highest version
possible. You can still build your
app to support older versions, but
setting the build target to the latest
version allows you to optimize your
app for the latest devices.
If you don't see any targets listed,
you need to install some using the
Android SDK Manager tool. See
Adding Platforms and Packages .
3. Execute:
android create project --target <target-id> --name MyFirstApp \
--path <path-to-workspace>/MyFirstApp --activity MainActivity \
--package com.example.myfirstapp
Replace <target-id> with an id
from the list of targets (from the
previous step) and replace <path-
to-workspace> with the location
in which you want to save your
Android projects.
Your Android project is now set up
with several default configurations
and you’re ready to begin building
the app. Continue to the next
lesson.
Tip: Add the platform-tools/ as
well as the tools/ directory to your
PATH environment variable.
Monday, 2 December 2013
Lesson 1 android app craters
Setting Up the Action Bar PREVIOUS NEXT
In its most basic form, the action
bar displays the title for the activity
and the app icon on the left. Even
in this simple form, the action bar is
useful for all activities to inform
users about where they are and to
maintain a consistent identity for
your app.
Figure 1. An action bar with the app
icon and activity title.
Setting up a basic action bar
requires that your app use an
activity theme that enables the
action bar. How to request such a
theme depends on which version of
Android is the lowest supported by
your app. So this lesson is divided
into two sections depending on
which Android version is your lowest
supported.
Support Android 3.0 and Above
Only
Beginning with Android 3.0 (API
level 11), the action bar is included
in all activities that use the
Theme.Holo theme (or one of its
descendants), which is the default
theme when either the
targetSdkVersion or
minSdkVersion attribute is set to
"11" or greater.
So to add the action bar to your
activities, simply set either attribute
to 11 or higher. For example:
<manifest ... >
<uses-sdk android:minSdkVersion ="11" ... />
...
</manifest>
Note: If you've created a custom
theme, be sure it uses one of the
Theme.Holo themes as its parent.
For details, see Styling the Action
Bar .
Now the Theme.Holo theme is
applied to your app and all activities
show the action bar. That's it.
Support Android 2.1 and Above
Adding the action bar when running
on versions older than Android 3.0
(down to Android 2.1) requires that
you include the Android Support
Library in your application.
To get started, read the Support
Library Setup document and set up
the v7 appcompat library (once
you've downloaded the library
package, follow the instructions for
Adding libraries with resources).
Once you have the Support Library
integrated with your app project:
1. Update your activity so that it
extends ActionBarActivity. For
example:
public class MainActivity extends ActionBarActivity { ... }
2. In your manifest file, update either
the <application> element or
individual <activity> elements to
use one of the Theme.AppCompat
themes. For example:
<activity android:theme = "@style/Theme.AppCompat.Light" ... >
Note: If you've created a custom
theme, be sure it uses one of the
Theme.AppCompat themes as its
parent. For details, see Styling the
Action Bar .
Now your activity includes the action
bar when running on Android 2.1
(API level 7) or higher.
Remember to properly set your app's
API level support in the manifest:
<manifest ... >
<uses-sdk android:minSdkVersion ="7" android:targetSdkVersion = "18" />
...
</manifest>
Lesson 3 Another activity
Starting Another Activity PREVIOUS NEXT
After completing the previous lesson,
you have an app that shows an
activity (a single screen) with a text
field and a button. In this lesson,
you’ll add some code to
MainActivity that starts a new
activity when the user clicks the
Send button.
Respond to the Send Button
To respond to the button's on-click
event, open the
activity_main.xml layout file
and add the android:onClick
attribute to the <Button> element:
<Button
android:layout_width = "wrap_content"
android:layout_height = "wrap_content"
android:text = "@string/button_send"
android:onClick ="sendMessage" />
The android:onClick attribute’s
value, "sendMessage" , is the name
of a method in your activity that the
system calls when the user clicks
the button.
Open the MainActivity class
(located in the project's src/
directory) and add the
corresponding method:
/** Called when the user clicks the Send button */
public void sendMessage( View view ) {
// Do something in response to button
}
This requires that you import the
View class:
import android .view . View ;
Tip: In Eclipse, press Ctrl + Shift + O
to import missing classes (Cmd +
Shift + O on Mac).
In order for the system to match this
method to the method name given
to android:onClick , the signature
must be exactly as shown.
Specifically, the method must:
Be public
Have a void return value
Have a View as the only parameter
(this will be the View that was
clicked)
Next, you’ll fill in this method to
read the contents of the text field
and deliver that text to another
activity.
Build an Intent
An Intent is an object that
provides runtime binding between
separate components (such as two
activities). The Intent represents
an app’s "intent to do something."
You can use intents for a wide
variety of tasks, but most often
they’re used to start another
activity.
Inside the sendMessage() method,
create an Intent to start an activity
called DisplayMessageActivity:
Intent intent = new Intent ( this , DisplayMessageActivity. class );
The constructor used here takes two
parameters:
A Context as its first parameter
( this is used because the
Activity class is a subclass of
Context)
The Class of the app component to
which the system should deliver the
Intent (in this case, the activity
that should be started)
Note: The reference to
DisplayMessageActivity will
raise an error if you’re using an IDE
such as Eclipse because the class
doesn’t exist yet. Ignore the error
for now; you’ll create the class soon.
An intent not only allows you to
start another activity, but it can
carry a bundle of data to the activity
as well. Inside the sendMessage()
method, use findViewById() to
get the EditText element and add
its text value to the intent:
Intent intent = new Intent ( this , DisplayMessageActivit
EditText editText = ( EditText ) findViewById ( R . id. edit
String message = editText . getText(). toString ();
intent . putExtra( EXTRA_MESSAGE , message );
Note: You now need import
statements for
android.content.Intent and
android.widget.EditText .
You'll define the EXTRA_MESSAGE
constant in a moment.
An Intent can carry a collection of
various data types as key-value pairs
called extras . The putExtra()
method takes the key name in the
first parameter and the value in the
second parameter.
In order for the next activity to
query the extra data, you should
define the key for your intent's extra
using a public constant. So add the
EXTRA_MESSAGE definition to the
top of the MainActivity class:
public class MainActivity extends Activity {
public final static String EXTRA_MESSAGE = "com.example.myfirstapp.MESSAGE" ;
...
}
It's generally a good practice to
define keys for intent extras using
your app's package name as a prefix.
This ensures they are unique, in
case your app interacts with other
apps.
Start the Second Activity
To start an activity, call
startActivity() and pass it your
Intent. The system receives this
call and starts an instance of the
Activity specified by the Intent .
With this new code, the complete
sendMessage() method that's
invoked by the Send button now
looks like this:
/** Called when the user clicks the Send button */
public void sendMessage( View view ) {
Intent intent = new Intent( this , DisplayMessageActivity. class );
EditText editText = (EditText ) findViewById (R . id .edit_message );
String message = editText . getText(). toString ();
intent . putExtra (EXTRA_MESSAGE , message );
startActivity ( intent);
}
Now you need to create the
DisplayMessageActivity class in
order for this to work.
Create the Second Activity
To create a new activity using
Eclipse:
1. Click New in the toolbar.
2. In the window that appears, open
the Android folder and select
Android Activity . Click Next .
3. Select BlankActivity and click Next .
4. Fill in the activity details:
Project: MyFirstApp
Activity Name:
DisplayMessageActivity
Layout Name :
activity_display_message
Title : My Message
Hierarchial Parent :
com.example.myfirstapp.MainActivity
Navigation Type: None
Click Finish .
If you're using a different IDE or the
command line tools, create a new
file named
DisplayMessageActivity.java
in the project's src/ directory, next
to the original
MainActivity.java file.
Open the
DisplayMessageActivity.java
file. If you used Eclipse to create
this activity:
The class already includes an
implementation of the required
onCreate() method.
There's also an implementation of
the onCreateOptionsMenu()
method, but you won't need it for
this app so you can remove it.
There's also an implementation of
onOptionsItemSelected() which
handles the behavior for the action
bar's Up behavior. Keep this one the
way it is.
Because the ActionBar APIs are
available only on HONEYCOMB (API
level 11) and higher, you must add a
condition around the
getActionBar() method to check
the current platform version.
Additionally, you must add the
@SuppressLint("NewApi") tag to
the onCreate() method to avoid
lint errors.
The DisplayMessageActivity
class should now look like this:
public class DisplayMessageActivity extends Activity {
@SuppressLint ( "NewApi" )
@Override
protected void onCreate (Bundle savedInstanceState ) {
super. onCreate ( savedInstanceState);
setContentView ( R .layout . activity_display_message );
// Make sure we're running on Honeycomb or higher to use ActionBar APIs
if ( Build .VERSION. SDK_INT >= Build. VERSION_CODES .HONEYCOMB ) {
// Show the Up button in the action bar.
getActionBar (). setDisplayHomeAsUpEnabled( true );
}
}
@Override
public boolean onOptionsItemSelected ( MenuItem item ) {
switch ( item . getItemId()) {
case android .R . id .home :
NavUtils . navigateUpFromSameTask(this );
return true ;
}
return super .onOptionsItemSelected ( item );
}
}
If you used an IDE other than
Eclipse, update your
DisplayMessageActivity class
with the above code.
All subclasses of Activity must
implement the onCreate()
method. The system calls this when
creating a new instance of the
activity. This method is where you
must define the activity layout with
the setContentView() method
and is where you should perform
initial setup for the activity
components.
Note: If you are using an IDE other
than Eclipse, your project does not
contain the
activity_display_message
layout that's requested by
setContentView() . That's OK
because you will update this method
later and won't be using that layout.
Add the title string
If you used Eclipse, you can skip to
the next section , because the
template provides the title string for
the new activity.
If you're using an IDE other than
Eclipse, add the new activity's title
to the strings.xml file:
<resources>
...
<string name ="title_activity_display_message" > My Message </string>
</resources>
Add it to the manifest
All activities must be declared in
your manifest file,
AndroidManifest.xml , using an
<activity> element.
When you use the Eclipse tools to
create the activity, it creates a
default entry. If you're using a
different IDE, you need to add the
manifest entry yourself. It should
look like this:
<application ... >
...
<activity
android:name ="com.example.myfirstapp.DisplayMessageActivity"
android:label = "@string/title_activity_display_message"
android:parentActivityName = "com.example.myfirstapp.MainActivity" >
<meta-data
android:name = "android.support.PARENT_ACTIVITY"
android:value ="com.example.myfirstapp.MainActivity" />
</activity>
</application>
The
android:parentActivityName
attribute declares the name of this
activity's parent activity within the
app's logical hierarchy. The system
uses this value to implement default
navigation behaviors, such as Up
navigation on Android 4.1 (API level
16) and higher. You can provide the
same navigation behaviors for older
versions of Android by using the
Support Library and adding the
<meta-data> element as shown
here.
Note: Your Android SDK should
already include the latest Android
Support Library. It's included with
the ADT Bundle but if you're using a
different IDE, you should have
installed it during the Adding
Platforms and Packages step. When
using the templates in Eclipse, the
Support Library is automatically
added to your app project (you can
see the library's JAR file listed
under Android Dependencies ). If
you're not using Eclipse, you need to
manually add the library to your
project—follow the guide for setting
up the Support Library then return
here.
If you're developing with Eclipse,
you can run the app now, but not
much happens. Clicking the Send
button starts the second activity but
it uses a default "Hello world" layout
provided by the template. You'll
soon update the activity to instead
display a custom text view, so if
you're using a different IDE, don't
worry that the app won't yet
compile.
Receive the Intent
Every Activity is invoked by an
Intent, regardless of how the user
navigated there. You can get the
Intent that started your activity by
calling getIntent() and retrieve
the data contained within it.
In the DisplayMessageActivity
class’s onCreate() method, get the
intent and extract the message
delivered by MainActivity :
Intent intent = getIntent ();
String message = intent . getStringExtra( MainActivity . EXTRA_MESSAGE );
Display the Message
To show the message on the screen,
create a TextView widget and set
the text using setText(). Then
add the TextView as the root view
of the activity’s layout by passing it
to setContentView() .
The complete onCreate() method
for DisplayMessageActivity now
looks like this:
@Override
public void onCreate ( Bundle savedInstanceState ) {
super. onCreate ( savedInstanceState);
// Get the message from the intent
Intent intent = getIntent ();
String message = intent .getStringExtra (MainActivity . EXTRA_MESSAGE );
// Create the text view
TextView textView = new TextView( this );
textView . setTextSize( 40 );
textView . setText( message);
// Set the text view as the activity layout
setContentView ( textView);
}
You can now run the app. When it
opens, type a message in the text
field, click Send, and the message
appears on the second activity.
Figure 2. Both activities in the final
app, running on Android 4.0.
That's it, you've built your first
Android app!
To learn more, follow the link below
to the next class.
Lesson simple user interface
Building a Simple User
Interface PREVIOUS NEXT
The graphical user interface for an
Android app is built using a
hierarchy of View and ViewGroup
objects. View objects are usually UI
widgets such as buttons or text
fields and ViewGroup objects are
invisible view containers that define
how the child views are laid out,
such as in a grid or a vertical list.
Android provides an XML vocabulary
that corresponds to the subclasses
of View and ViewGroup so you can
define your UI in XML using a
hierarchy of UI elements.
Figure 1. Illustration of how
ViewGroup objects form branches in
the layout and contain other View
objects.
In this lesson, you'll create a layout
in XML that includes a text field and
a button. In the following lesson,
you'll respond when the button is
pressed by sending the content of
the text field to another activity.
Create a Linear Layout
Open the activity_main.xml file
from the res/layout/ directory.
Note: In Eclipse, when you open a
layout file, you’re first shown the
Graphical Layout editor. This is an
editor that helps you build layouts
using WYSIWYG tools. For this
lesson, you’re going to work directly
with the XML, so click the
activity_main.xml tab at the bottom
of the screen to open the XML
editor.
The BlankActivity template you chose
when you created this project
includes the activity_main.xml
file with a RelativeLayout root
view and a TextView child view.
First, delete the <TextView>
element and change the
<RelativeLayout> element to
<LinearLayout> . Then add the
android:orientation attribute
and set it to "horizontal" . The
result looks like this:
<? xml version = "1.0" encoding = "utf-8" ?>
<LinearLayout xmlns:android = "http://schemas.android.com/apk/res/android"
xmlns:tools = "http://schemas.android.com/tools"
android:layout_width = "match_parent"
android:layout_height = "match_parent"
android:orientation= "horizontal" >
</LinearLayout>
LinearLayout is a view group (a
subclass of ViewGroup ) that lays
out child views in either a vertical or
horizontal orientation, as specified
by the android:orientation
attribute. Each child of a
LinearLayout appears on the
screen in the order in which it
appears in the XML.
The other two attributes,
android:layout_width and
android:layout_height , are
required for all views in order to
specify their size.
Because the LinearLayout is the
root view in the layout, it should fill
the entire screen area that's
available to the app by setting the
width and height to
"match_parent" . This value
declares that the view should
expand its width or height to match
the width or height of the parent
view.
For more information about layout
properties, see the Layout guide.
Add a Text Field
To create a user-editable text field,
add an <EditText> element inside
the <LinearLayout> .
Like every View object, you must
define certain XML attributes to
specify the EditText object's
properties. Here’s how you should
declare it inside the
<LinearLayout> element:
<EditText android:id = "@+id/edit_message"
android:layout_width ="wrap_content"
android:layout_height = "wrap_content"
android:hint ="@string/edit_message" />
About these attributes:
android:id
This provides a unique identifier for
the view, which you can use to
reference the object from your app
code, such as to read and
manipulate the object (you'll see
this in the next lesson).
The at sign ( @) is required when
you're referring to any resource
object from XML. It is followed by
the resource type (id in this case), a
slash, then the resource name
(edit_message ).
The plus sign ( + ) before the resource
type is needed only when you're
defining a resource ID for the first
time. When you compile the app,
the SDK tools use the ID name to
create a new resource ID in your
project's gen/R.java file that
refers to the EditText element.
Once the resource ID is declared
once this way, other references to
the ID do not need the plus sign.
Using the plus sign is necessary only
when specifying a new resource ID
and not needed for concrete
resources such as strings or layouts.
See the sidebox for more information
about resource objects.
android:layout_width and
android:layout_height
Instead of using specific sizes for the
width and height, the
"wrap_content" value specifies
that the view should be only as big
as needed to fit the contents of the
view. If you were to instead use
"match_parent" , then the
EditText element would fill the
screen, because it would match the
size of the parent LinearLayout .
For more information, see the
Layouts guide.
android:hint
This is a default string to display
when the text field is empty.
Instead of using a hard-coded string
as the value, the "@string/
edit_message" value refers to a
string resource defined in a separate
file. Because this refers to a concrete
resource (not just an identifier), it
does not need the plus sign.
However, because you haven't
defined the string resource yet,
you’ll see a compiler error at first.
You'll fix this in the next section by
defining the string.
Note: This string resource has the
same name as the element ID:
edit_message . However, references
to resources are always scoped by
the resource type (such as id or
string), so using the same name
does not cause collisions.
Add String Resources
When you need to add text in the
user interface, you should always
specify each string as a resource.
String resources allow you to manage
all UI text in a single location, which
makes it easier to find and update
text. Externalizing the strings also
allows you to localize your app to
different languages by providing
alternative definitions for each
string resource.
By default, your Android project
includes a string resource file at
res/values/strings.xml . Add a
new string named
"edit_message" and set the value
to "Enter a message." (You can
delete the "hello_world" string.)
While you’re in this file, also add a
"Send" string for the button you’ll
soon add, called "button_send" .
The result for strings.xml looks
like this:
<? xml version = "1.0" encoding = "utf-8" ?>
<resources>
<string name ="app_name" > My First App </string>
<string name ="edit_message" > Enter a message </string>
<string name ="button_send" > Send </string>
<string name ="action_settings" > Settings </string>
<string name ="title_activity_main" > MainActivity </string>
</resources>
For more information about using
string resources to localize your app
for other languages, see the
Supporting Different Devices class.
Add a Button
Now add a <Button> to the layout,
immediately following the
<EditText> element:
<Button
android:layout_width ="wrap_content"
android:layout_height = "wrap_content"
android:text ="@string/button_send" />
The height and width are set to
"wrap_content" so the button is
only as big as necessary to fit the
button's text. This button doesn't
need the android:id attribute,
because it won't be referenced from
the activity code.
Make the Input Box Fill in the
Screen Width
The layout is currently designed so
that both the EditText and
Button widgets are only as big as
necessary to fit their content, as
shown in figure 2.
Figure 2. The EditText and
Button widgets have their widths
set to "wrap_content" .
This works fine for the button, but
not as well for the text field,
because the user might type
something longer. So, it would be
nice to fill the unused screen width
with the text field. You can do this
inside a LinearLayout with the
weight property, which you can
specify using the
android:layout_weight
attribute.
The weight value is a number that
specifies the amount of remaining
space each view should consume,
relative to the amount consumed by
sibling views. This works kind of like
the amount of ingredients in a drink
recipe: "2 parts vodka, 1 part coffee
liqueur" means two-thirds of the
drink is vodka. For example, if you
give one view a weight of 2 and
another one a weight of 1, the sum
is 3, so the first view fills 2/3 of the
remaining space and the second
view fills the rest. If you add a third
view and give it a weight of 1, then
the first view (with weight of 2) now
gets 1/2 the remaining space, while
the remaining two each get 1/4.
The default weight for all views is 0,
so if you specify any weight value
greater than 0 to only one view, then
that view fills whatever space
remains after all views are given the
space they require. So, to fill the
remaining space in your layout with
the EditText element, give it a
weight of 1 and leave the button
with no weight.
<EditText
android:layout_weight = "1"
... />
In order to improve the layout
efficiency when you specify the
weight, you should change the width
of the EditText to be zero (0dp).
Setting the width to zero improves
layout performance because using
"wrap_content" as the width
requires the system to calculate a
width that is ultimately irrelevant
because the weight value requires
another width calculation to fill the
remaining space.
<EditText
android:layout_weight = "1"
android:layout_width ="0dp"
... />
Figure 3 shows the result when you
assign all weight to the EditText
element.
Figure 3. The EditText widget is
given all the layout weight, so fills
the remaining space in the
LinearLayout.
Here’s how your complete layout file
should now look:
<? xml version = "1.0" encoding = "utf-8" ?>
<LinearLayout xmlns:android = "http://schemas.android.com/apk/res/android"
xmlns:tools = "http://schemas.android.com/tools"
android:layout_width = "match_parent"
android:layout_height = "match_parent"
android:orientation= "horizontal" >
<EditText android:id = "@+id/edit_message"
android:layout_weight = "1"
android:layout_width ="0dp"
android:layout_height = "wrap_content"
android:hint ="@string/edit_message" />
<Button
android:layout_width ="wrap_content"
android:layout_height = "wrap_content"
android:text ="@string/button_send" />
</LinearLayout>
This layout is applied by the default
Activity class that the SDK tools
generated when you created the
project, so you can now run the app
to see the results:
In Eclipse, click Run from the
toolbar.
Or from a command line, change
directories to the root of your
Android project and execute:
ant debug
adb install bin / MyFirstApp- debug . apk
Continue to the next lesson to learn
how you can respond to button
presses, read content from the text
field, start another activity, and
more.
Lesson 2 Running app android
Running Your App PREVIOUS NEXT
If you followed the previous lesson
to create an Android project, it
includes a default set of "Hello
World" source files that allow you to
immediately run the app.
How you run your app depends on
two things: whether you have a real
Android-powered device and whether
you're using Eclipse. This lesson
shows you how to install and run
your app on a real device and on the
Android emulator, and in both cases
with either Eclipse or the command
line tools.
Before you run your app, you should
be aware of a few directories and
files in the Android project:
AndroidManifest.xml
The manifest file describes the
fundamental characteristics of the
app and defines each of its
components. You'll learn about
various declarations in this file as
you read more training classes.
One of the most important elements
your manifest should include is the
<uses-sdk> element. This declares
your app's compatibility with
different Android versions using the
android:minSdkVersion and
android:targetSdkVersion
attributes. For your first app, it
should look like this:
<manifest xmlns:android = "http://schemas.android.com/apk/res/android" ... >
<uses-sdk android:minSdkVersion ="8" android:targetSdkVersion = "17" />
...
</manifest>
You should always set the
android:targetSdkVersion as
high as possible and test your app
on the corresponding platform
version. For more information, read
Supporting Different Platform
Versions.
src/
Directory for your app's main source
files. By default, it includes an
Activity class that runs when your
app is launched using the app icon.
res/
Contains several sub-directories for
app resources. Here are just a few:
drawable-hdpi/
Directory for drawable objects (such
as bitmaps) that are designed for
high-density (hdpi) screens. Other
drawable directories contain assets
designed for other screen densities.
layout/
Directory for files that define your
app's user interface.
values/
Directory for other various XML files
that contain a collection of
resources, such as string and color
definitions.
When you build and run the default
Android app, the default Activity
class starts and loads a layout file
that says "Hello World." The result is
nothing exciting, but it's important
that you understand how to run your
app before you start developing.
Run on a Real Device
If you have a real Android-powered
device, here's how you can install
and run your app:
1. Plug in your device to your
development machine with a USB
cable. If you're developing on
Windows, you might need to install
the appropriate USB driver for your
device. For help installing drivers,
see the OEM USB Drivers document.
2. Enable USB debugging on your
device.
On most devices running Android
3.2 or older, you can find the option
under Settings > Applications >
Development .
On Android 4.0 and newer, it's in
Settings > Developer options .
Note: On Android 4.2 and newer,
Developer options is hidden by
default. To make it available, go to
Settings > About phone and tap
Build number seven times. Return
to the previous screen to find
Developer options.
To run the app from Eclipse:
1. Open one of your project's files and
click Run from the toolbar.
2. In the Run as window that appears,
select Android Application and click
OK .
Eclipse installs the app on your
connected device and starts it.
Or to run your app from a command
line:
1. Change directories to the root of
your Android project and execute:
ant debug
2. Make sure the Android SDK
platform-tools/ directory is
included in your PATH environment
variable, then execute:
adb install bin/MyFirstApp-debug.apk
3. On your device, locate MyFirstActivity
and open it.
That's how you build and run your
Android app on a device! To start
developing, continue to the next
lesson.
Run on the Emulator
Whether you're using Eclipse or the
command line, to run your app on
the emulator you need to first create
an Android Virtual Device (AVD). An
AVD is a device configuration for the
Android emulator that allows you to
model different devices.
To create an AVD:
1. Launch the Android Virtual Device
Manager:
a. In Eclipse, click Android Virtual
Device Manager from the
toolbar.
b. From the command line, change
directories to <sdk>/tools/
and execute:
android avd
2. In the Android Virtual Device
Manager panel, click New .
3. Fill in the details for the AVD. Give
it a name, a platform target, an SD
card size, and a skin (HVGA is
default).
4. Click Create AVD .
5. Select the new AVD from the Android
Virtual Device Manager and click
Start .
6. After the emulator boots up, unlock
the emulator screen.
To run the app from Eclipse:
1. Open one of your project's files and
click Run from the toolbar.
2. In the Run as window that appears,
select Android Application and click
OK .
Eclipse installs the app on your AVD
and starts it.
Or to run your app from the
command line:
1. Change directories to the root of
your Android project and execute:
ant debug
2. Make sure the Android SDK
platform-tools/ directory is
included in your PATH environment
variable, then execute:
adb install bin/MyFirstApp-debug.apk
3. On the emulator, locate
MyFirstActivity and open it.
That's how you build and run your
Android app on the emulator! To
start developing, continue to the
next lesson .
Sunday, 1 December 2013
Without root games for galaxy y
Contract Killer HDGet ready to be a contract killer...comes with awesome graphics..I bet you will like it..
* n**o rooting, no chainfire*
*Get it here :*
APK : LINK
SD DATA : app download sd data is best way for sd data
*extract the data file and you will get a folder. In that folder, there will be a folder named com.flu.gladiator.ck ..place this folder in /sdcard/android/data/ *
ENJOY
Description :
Enforcer or Assassin, call it what
you like - you're a CONTRACT
KILLER.
They might call you an enforcer, or
an assassin. Call it what you like -
you're a CONTRACT KILLER.
Pulled into a world of bounty
hunters, mobsters and criminals,
you must check in with your
contacts and accept SECRET
MISSIONS that only you can
handle. Select your WEAPON OF
CHOICE from an inventory of sniper
rifles, assault rifles and machine
guns. Locate your target, zoom in,
take aim and GO FOR THE
HEADSHOT to earn cold hard cash.
You might eliminate a crime boss
and escape without being spotted,
or you might walk straight into an
AMBUSH...
WELCOME TO CENTRAL CITY
Prepare for your mission and then
jump into one of many vantage
points within 5 gritty 3D locations
UNLIMITED MISSIONS
17 Story Missions and unlimited
Random Missions provide cash, XP
and lots of action
DEADLY WEAPONS
20 distinct weapons including
handguns, sniper rifles, machine
guns and assault rifles
ALIVE OR DEAD
Use the Tranquilizer Gun to
capture your target or put them
down... permanently
how crate android app on mobile
crates android app on android mobile
go to play store and downlode aide android
How create android app
Android Developer Tools (ADT) Bundle for Windows
1)
Install java firstBrowse http://developer.android.com/sdk/index.html. Click Download the SDK ADT Bundle for Windows.
2) Click I Agree. Choose 32-bit. Click Download the SDK ADT Bundle for Windows.
3) Unzip the file, preferably to the root of your machine. The folder eclipse contains the eclipse IDE specifically set for Android Development. The folder sdk contains Android development tools.
4) Go into eclipse folder. Double-click eclipse.exe. Android Splash Screen pops up.
5) During the first time running, Eclipse would ask for a workspace. Enter relative path for workspace.
6) A welcome page is displayed.
7) Go to menu Help/About ADT.
8) Go to Window/Preferences. Check.
9) Go to Window/Android Virtual Device Manager Check.
10) Add New Virtual Device.
10.1) Start the Device.
10.2) Virtual Android Machine is started.
11) Go to File\New\Other... Choose Android Application Project.
12) New Android Application. Fill-in details. Click Next.
13) Project Configuration. Click Next.
14) Configure Launcher Icon. Click Next.
15) Create Activity. Click Next.
16) New Blank Activity. Click Finish.
17) Go to menu Run\Run as... Android Application.
Hey gays frontline commando games for galaxy y
Hey gays many blogspot say you frontline commando game support but not support galaxy y
